The B1019 code indicates a manufacturer-specific fault related to the vehicle's body, often associated with the seat belt tension sensor[2]. This diagnostic trouble code (DTC) can appear in various car models, including Nissan vehicles like the Titan, Xterra, and Sakura[1][9][10]. It often points to a failure or malfunction in the belt tension sensor unit[4][6][9][10]. When this code is triggered, the airbag warning light usually illuminates, signaling a problem within the Supplemental Restraint System (SRS)[3][6][9][10]. Addressing this issue promptly is crucial for safety, as the SRS may not function correctly in an accident[3][6][9][10].
The B1019 code is not generic; it's manufacturer-specific, meaning its precise definition can vary slightly depending on the vehicle's make and model[2]. However, it generally relates to a problem within the seat belt pre-tensioner system[7]. The pre-tensioner is designed to tighten the seat belt during a collision, securing the occupant more firmly in their seat[7].
Several potential causes can trigger the B1019 code:
- Faulty Belt Tension Sensor: The sensor itself may be defective due to wear, damage, or electrical issues[2].
- Wiring Problems: Damaged, corroded, or loose wiring in the sensor circuit can cause the code[2].
- Connector Issues: Poor connections at the sensor or module connectors can disrupt the signal[2].
- SRS Module Failure: In some cases, the Supplemental Restraint System (SRS) module itself may be faulty[3].
- Accident or Deployment: If the vehicle has been in an accident and the pre-tensioners have deployed, the code will likely appear[6][9][10].
- SDM (Sensing Diagnostic Module) Issues: Problems with the SDM, such as incorrect programming or a mismatch of components, can trigger the B1019 code[3].
The most obvious symptom is the illuminated airbag warning light[3][6][9][10]. Other potential symptoms include:
- Non-functioning Seat Belt Pre-tensioner: The seat belt may not tighten correctly during a collision.
- SRS Malfunction: The entire SRS system may be compromised, affecting airbag deployment.
- Error Messages: Diagnostic tools will display the B1019 code and potentially related sub-codes[2].
Before attempting any repairs, gather the necessary tools and materials:
- OBD-II Scanner: To read and clear the B1019 code[1].
- Multimeter: To test wiring continuity and voltage[2].
- Socket Set & Wrenches: To remove and install components.
- Screwdrivers: Various sizes for removing trim panels and screws.
- Wiring Repair Kit: Including connectors, wire, and crimping tool[1].
- Replacement Belt Tension Sensor (if needed): Ensure it's the correct part for your vehicle.
- Service Manual: For your specific vehicle model, providing wiring diagrams and component locations[7].
- CONSULT-II or C-III (Nissan specific): Helpful for checking and erasing airbag codes, especially on Nissan vehicles[4].
Working with the SRS system can be dangerous if proper precautions are not followed. Always disconnect the battery and wait at least 10 minutes before beginning any work on the system. This allows the capacitors in the SRS module to discharge, reducing the risk of accidental airbag deployment.
Step-by-Step Repair Guide
1. Diagnose the Code:
- Use an OBD-II scanner to confirm the presence of the B1019 code[1].
- Note any sub-codes or additional codes that appear[2]. These can provide more specific information about the problem.
2. Inspect the Belt Tension Sensor and Wiring:
- Locate the belt tension sensor on the affected seat belt assembly[7]. Consult your service manual for the exact location.
- Visually inspect the sensor and its wiring harness for any signs of damage, corrosion, or loose connections[2].
- Pay close attention to the connector, ensuring it is clean and securely attached.
3. Check Wiring Continuity:
- Disconnect the battery and wait 10 minutes.
- Disconnect the belt tension sensor connector.
- Use a multimeter to check the continuity of the wiring between the sensor connector and the SRS module[2]. Refer to your service manual for the correct wiring diagram.
- Repair any broken or damaged wires using a wiring repair kit[1].
4. Test Sensor Voltage:
- Reconnect the battery.
- With the sensor connected, use a multimeter to check the voltage at the sensor connector[2].
- Compare the voltage reading to the specification in your service manual.
- If the voltage is outside the specified range, there may be a problem with the SRS module or the wiring.
5. Address Connector Issues:
- Clean the sensor and module connector with electrical contact cleaner[2].
- Ensure the connector pins are not bent or damaged.
- Apply dielectric grease to the connector to prevent corrosion.
6. Replace the Belt Tension Sensor (If Necessary):
- If the sensor is faulty, replace it with a new one[7].
- Ensure the replacement sensor is the correct part for your vehicle.
- Install the new sensor and connect the wiring harness.
7. Check the SDM (Sensing Diagnostic Module):
- If the code persists, the SDM may be the issue[3].
- Ensure the SDM is correctly programmed for your vehicle[3].
- If necessary, have the SDM reprogrammed by a qualified technician[3].
8. Clear the Code:
- Use an OBD-II scanner to clear the B1019 code[1].
- Start the vehicle and check if the airbag warning light remains off.
- If the code returns, further diagnosis may be necessary.
In some Nissan Titan models, a blinking airbag light and the B1019 code can be caused by wiring issues under the seat[1]. Here's how to address this specific problem:
1. Access the Wiring:
- Locate the wiring connectors under the driver or passenger seat[1].
- These connectors are typically for the seat belt pre-tensioner and tension sensor.
2. Inspect the Connectors:
- Check for any loose, damaged, or corroded connectors[2].
- Pay particular attention to the yellow and black wires, as these are often associated with airbag issues[1].
3. Repair the Wiring:
- If you find any loose connections, reconnect them securely[2].
- If the wires are damaged, use a wiring repair kit to splice in new sections of wire[1].
- Ensure all connections are properly crimped and insulated.
4. Test the Repair:
- Reconnect the battery.
- Use an OBD-II scanner to clear the B1019 code[1].
- Start the vehicle and check if the airbag light remains off.
- If the light continues to blink, you may need to further investigate the wiring or replace the affected sensor.
If the B1019 code persists after addressing the wiring and sensor, the SRS airbag control module may need to be reset[6][9][10]. This is often necessary after an accident, as crash data can be stored in the module, triggering the code[6][9][10].
Several companies offer airbag module reset services[6][9][10]. Here's how the process typically works:
1. Purchase the Reset Service:
- Find a reputable company that offers airbag module reset services[6][9][10].
- Purchase the service online or by phone.
2. Remove the Airbag Module:
- Locate the airbag module in your vehicle. Consult your service manual for the exact location.
- Disconnect the battery and wait 10 minutes.
- Remove the airbag module from the vehicle.
3. Ship the Module:
- Package the airbag module securely and ship it to the reset service company[6][9][10].
4. Module Reset:
- The company will reset the module, clearing any crash data and restoring it to its original condition[6][9][10].
5. Return and Reinstall:
- The reset module will be shipped back to you.
- Reinstall the module in your vehicle.
- Reconnect the battery.
- Use an OBD-II scanner to clear any remaining codes.
While many B1019 issues can be resolved with careful DIY repairs, there are situations where professional help is necessary:
- Uncertainty: If you are not comfortable working with electrical systems or the SRS system, seek professional assistance.
- Persistent Code: If the B1019 code persists after attempting the above repairs, it may indicate a more complex problem that requires specialized diagnostic equipment.
- SRS Module Issues: If you suspect a problem with the SRS module itself, it's best to consult a qualified technician.
- Accident Involvement: If the code appeared after an accident, the SRS system may have sustained damage that requires professional repair.
The B1019 code, indicating a fault in the belt tension sensor unit, can be a concerning issue, potentially compromising the effectiveness of your vehicle's SRS[2][3][7]. By systematically diagnosing the problem, inspecting the wiring and sensor, and, if necessary, resetting the airbag module, you can often resolve this issue[1][2][6][9][10]. However, safety should always be a priority[4]. If you're uncomfortable with any aspect of the repair process, it's best to seek the help of a qualified professional[4]. Addressing the B1019 code promptly ensures that your vehicle's safety systems are functioning correctly, providing crucial protection in the event of a collision[3][6][9][10].
The B1019 code is a manufacturer-specific diagnostic trouble code (DTC) that typically indicates a fault with the belt tension sensor unit[2][7]. This sensor is part of the Supplemental Restraint System (SRS) and is designed to tighten the seat belt during a collision[7]. The exact definition of the code can vary depending on the vehicle's make and model[2].
It is not recommended to drive with the B1019 code[3][6][9][10]. This code indicates a potential problem with the SRS, which may not function correctly in an accident[3][6][9][10]. Driving with a compromised SRS puts you and your passengers at risk. It's best to address the issue as soon as possible.
To clear the B1019 code, you will need an OBD-II scanner[1]. Plug the scanner into the diagnostic port of your vehicle, read the stored codes, and then use the scanner's function to clear the codes[1]. After clearing the code, start the vehicle and see if the code returns. If it does, it means the underlying problem has not been resolved.
The cost to fix the B1019 code can vary widely depending on the cause of the problem[6][9][10]. If the issue is a simple wiring problem, the repair may cost less than $100[1][2]. However, if the belt tension sensor or the SRS module needs to be replaced, the cost could range from $200 to $1000 or more[7]. Resetting the airbag module can cost around $50-$100[6][9][10].
Yes, the B1019 code can be related to an accident[6][9][10]. If the vehicle has been in an accident and the seat belt pre-tensioners have deployed, the B1019 code will likely appear[6][9][10]. In this case, the pre-tensioners will need to be replaced, and the SRS module may need to be reset[6][9][10].
