Load Direction | Installation |

|
|
Specifications | Technique |
Capacity | 10,20,50,100kg |
Sensitivity | 2.0±10%mV/V |
Zero Balance | ±0.02mV/V |
Creep | 0.0166%F.S. |
Non-linearity | 0.0166%F.S. |
Hysteresis | 0.0166%F.S. |
Repeatability | 0.018%F.S. |
Input Impedance | 380±15Ω |
Output Impddance | 350±10Ω |
Temp.efliect on sensitivity | 0.0175%F.S./10℃ |
Tamp.efliect on zero | 0.0125%F.S./10℃ |
Insulation Resistance | ≥500MΩ/100V(DC) |
Recommended Excitation | 5V |
Max. Excitation | 12V |
Compensated Temp. Range | -10~40℃ |
Operating Temp. Range | -20~50℃ |
Safe Overload | 150%F.S. |
Ultimate Overload | 200%F.S. |
Cable Size | Φ5.4x3000mm |
Material | Stainless Steel |
Maximum size of the scale
| 500mmX400mm |
